40khz 35W Ultrasonic Piezoelectric Cleaning Transducer Plate Electric Ceramic Sheet Module Board For arduino
Default Title
Prix promotionnel
$19.99
Prix régulier $27.99
Passer aux informations sur le produit
40khz 35W Ultrasonic Piezoelectric Cleaning Transducer Plate Electric Ceramic Sheet Module Board For arduino
Prix promotionnel
$19.99
Prix régulier $27.99
Expédition calculée lors du paiement.
SPECIFICATIONS
Brand Name: NONE
Choice: yes
Origin: Mainland China
semi_Choice: yes
Description
Product size and performance parameters:
Resonant frequency (KHz): 40 ± 1
Static capacitance (pF): 8500 ± 10%
Resonance impedance (Ω): ≤20Ω
Dimensions: 50 * 2.6mm (diameter * height)
Power (W): 35w
Insulation resistance (2500V DC): ≥ 100MΩ
Features:
1. Low heat.
2. Good thermal stability.
3. Frequency and static capacitance strong consistency.
4. Resonant impedance is low.
5. The average length of life.
6. It can be widely used in a variety of ultrasonic cleaning equipment.
7. High performance: mechanical Q value, high vibration efficiency
Special Note:
Received ceramic sheet is not terminal and connecting terminals
Package contains:
1 x Ultrasonic electric ceramic sheet
