Magnetic-assisted Electric Contact Pressure Gaug Electrical Contact Pressure Gauge YXC-100

Magnetic-assisted Electric Contact Pressure Gaug Electrical Contact Pressure Gauge YXC-100

0-16Mpa
$46.99 $64.99
Passer aux informations sur le produit
Magnetic-assisted Electric Contact Pressure Gaug Electrical Contact Pressure Gauge YXC-100
  • Magnetic-assisted Electric Contact Pressure Gaug Electrical Contact Pressure Gauge YXC-100
  • Magnetic-assisted Electric Contact Pressure Gaug Electrical Contact Pressure Gauge YXC-100
  • Magnetic-assisted Electric Contact Pressure Gaug Electrical Contact Pressure Gauge YXC-100
  • Magnetic-assisted Electric Contact Pressure Gaug Electrical Contact Pressure Gauge YXC-100
Magnetic-assisted Electric Contact Pressure Gaug Electrical Contact Pressure Gauge YXC-100

Magnetic-assisted Electric Contact Pressure Gaug Electrical Contact Pressure Gauge YXC-100

$46.99 $64.99
Expédition calculée lors du paiement.
Pressure Range

SPECIFICATIONS

Brand Name: easyelec

Model Number: YXC-100

Origin: Mainland China



Specification: YXC-100 magnetic auxiliary type electric contact pressure gauge
Dial diameter: 100mm
Connector size: M20 * 1.5 (can make for 3/8" and 1/2", please leave message in the order when you have speical requirement)
Measuring range: 0-1.6MPA (all specifications)
Installation form: radial
Contact power: 30VA (resistance load, magnetic auxiliary type)
Operating voltage: 220V 380V general purpose
Control form: upper and lower limit
Accuracy level: level 1.6
Material: Housing carbon steel, movement copper, joint copper
Color: black, joint metal color
Using environmental conditions: -40 ~ 70 degrees, relative humidity is not greater than 85%
